Rosemount 8732 - Page 104

Reference Manual
00809-0100-4663, Rev BA
January 2010
Rosemount 8732
B-12
Table B-7. Electrical Data
Rosemount 8732 Flow Transmitter
Power supply: 250 V AC, 1 A or 42 Vdc, 2,5 A, 20 W maximum
Foundation fieldbus
output:
30 V DC, 30 mA, 1 W maximum
Rosemount 8705 and 8711 Sensors
Coil excitation
circuit:
40 V DC (pulsed), 0,5 A, 20 W maximum
Electrode circuit: Intrinsically Safe Electrode Circuit: U
i
= 5 V, l
i
= 0.2 mA, P
i
= 1 mW,
U
m
= 250 V
Rosemount 8732E Flow Transmitter:
Power supply: 250 V AC, 1 A or 42 Vdc, 2, 5 A, 20 W maximum
FOUNDATION
™
fieldbus output:
Intrinsically Safe Output:
U
i
= 30 V
I
i
= 380 mA
P
i
= 5,32 W
C
i
= 924 pF
L
i
= 0 mH
