Reference Manual
00809-0100-4663, Rev BA
January 2010
E-13
Rosemount 8732
Model 10D1465 and
Model 10D1475 Sensors
(Integral) to 8732
Transmitter
Connect coil drive and electrode cables as shown in Figure E-10.
Figure E-10. Wiring Diagram for
Fischer and Porter Sensor
Model 10D1465 and Model
10D1475 (Integral) and
Rosemount 8732
Table E-11. Fischer and Porter
Model 10D1465 and 10D1475
Sensor Wiring Connections
2A
2
1
5
6
16
3
CT
M2
M1
MR
Electrode
Connections
Coil Connections
ROSEMOUNT 8732 TRANSMITTER
Disconnect
Rosemount 8732
Fischer and Porter Model 10D1465 and
10D1475 Sensors
1MR
2 M1
3
17 3
18 1
19 2
This is a pulsed DC magnetic flowmeter.
Do not connect AC power to the sensor
or to terminals 1 and 2 of the
transmitter, or replacement of the
electronics board will be necessary.
