Rosemount 8732
G-4
TRANSDUCER BLOCK
ERRORS
The following conditions are reported in the BLOCK_ERR and XD_ERROR
parameters. Conditions in italics are inactive for the transducer block and are
given here only for your reference.
Table G-4. Transducer
BLOCK_ERR and XD_ERR
Conditions
Condition
Number
Condition Name and Description
1 Block Configuration Error
2 Link Configuration Error
3 Simulate Active
4 Local Override
5 Device Fault State Set
6 Device Needs Maintenance Soon
7 Input Failure/Process Variable Has Bad Status
8 Output Failure
9 Memory Failure
10 Lost Static Data
11 Lost NV Data
12 Readback Check Failed
13 Device Needs Maintenance Now
14 Power Up: The device was just powered-up.
15 Out of Service: The actual mode is out of service.
16 Unspecified Error: An unidentified error occurred.
17 General Error: A general error that cannot be specified below occurred.
18 Calibration Error: An error occurred during calibration of the device, or
a calibration error was detected during normal operations.
19 Configuration Error: An error occurred during configuration of the
device, or a configuration error was detected during normal operations.
20 Electronics Failure: An electrical component failed.
21 Mechanical Failure: A mechanical component failed.
22 I/O Failure: An input/output (I/O) failure occurred.
23 Data Integrity Error: Data stored in the device are no longer valid due
to a nonvolatile memory checksum failure, a data verify after write
failure, etc.
24 Software Error: The software has detected an error due to an improper
interrupt service routine, an arithmetic overflow, a watchdog time-out,
etc.
25 Algorithm Error: The algorithm used in the transducer block produced
an error due to overflow, data reasonableness failure, etc.
