10
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
Table 6. ZoneFlex 2942/7942 rear panel elements
Number Item Name Description
1 Power Adapter Plug Connect the power adapter to this socket. (Input
110-240V AC, Output 12V 1.0A DC). Power can also
be supplied via 10/100 POE port.
2 Lock Hasp The lock hasp works with a cable or Ruckus mounts.
The recommended lock type is Masterlock 120 series
(D, T, Q, KAD types).
3 External RP-SMA
Connector
• ZoneFlex 2942: One external antenna connector.
• ZoneFlex 7942: Two external antenna connectors.
4 LAN Ports • ZoneFlex 2942: Two RJ-45 ports, supporting 10/
100 POE (Power over Ethernet) and 10/100Mbps
connections.
• ZoneFlex 7942: Two RJ-45 ports, supporting 10/
100/1000 POE (Power over Ethernet) and 10/100/
1000Mbps connections.
5 OPTIONAL Button Not active in this model at this time.
6 SOFT RESET
Button
Use to reset AP. This is a normal reset and does not
set AP back to factory defaults.
