Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex 2942/7942
The side panel of ZoneFlex 2942/7942 features four LED indicators that can be used
to assess both device and network status. The rear view displays the connector panel,
which includes the LAN ports and the optional external antenna connection. Refer to
the following illustrations and tables to learn more.
Side Panel Features
The ZoneFlex 2942/7942 chassis includes a Kensington lock (on the side of the unit
opposite the OPT and DIR LEDs) and a lockable “sliding door” (shown in Figure 3
)
that hides and protects the rear connector I/O panel and status LEDs. As your AP may
be placed in a public location, the lock and door mechanisms can help prevent
tampering or theft.
Figure 3. ZoneFlex 2942/7942 side panel features
