Installing the Access Point
Step 2: Verify Access Point Operation
Check the LEDs
Perform a spot-check using the LEDs to verify that the Access Point is operating
normally. Refer to the following sections for information on how to check the LEDs on
each ZoneFlex AP model.
ZoneFlex 2925
If the Access Point is operating normally and your wireless client was able to associate
with it:
■ The LED is green.
■ The LED is green, and if traffic if passing through, it flashes green. Open a Web
browser window, type www.ruckuswireless.com in the address bar, and then
press <Enter>. The LED should flash green as your wireless client connects
to the Ruckus Wireless Web site through the Access Point.
■ The LED is green. This indicates that at least one wireless client is connected to
the Access Point’s WLAN service.
ZoneFlex 2942/7942
If the Access Point is operating normally and your wireless client was able to associate
with it:
■ The WLAN LED is green, and if traffic if passing through, it flashes green. Open
a Web browser window, type www.ruckuswireless.com in the address bar,
and then press <Enter>. The WLAN LED should flash green (two flashes every
second) as your wireless client connects to the Ruckus Wireless Web site through
the Access Point.
■ If you do not have Ruckus Wireless ZoneDirector on the network, the DIR LED is
off. This indicates that the Access Point is operating in standalone mode. If there
is a ZoneDirector device on the network, the DIR LED is green.
ZoneFlex 7962
If the Access Point is operating normally and your wireless client was able to associate
with it:
■ The 2.4G or 5G LED is green, and if traffic if passing through, it flashes green.
Open a Web browser window, type www.ruckuswireless.com in the address
bar, and then press <Enter>. The 2.4G or 5G LED should flash green (two flashes
every second) as your wireless client connects to the Ruckus Wireless Web site
through the Access Point.
■ If you do not have Ruckus Wireless ZoneDirector on the network, the DIR LED is
off. This indicates that the Access Point is operating in standalone mode. If there
is a ZoneDirector device on the network, the DIR LED is green.
