Navigating the Web Interface
Monitoring the Wireless Bridge Status
Monitoring the Local Bridge
The Status > Bridge page shows current status and configuration information about
the Ruckus Wireless device.
Channel Displays the current channel, and indicates whether
SmartSelect is enabled.
Channel Width Displays the width of the channel (40MHz or 20MHz).
Country Code Displays the current country/region setting.
SSID Displays the name of the wireless network.
BSSID Displays the MAC address of the wireless network.
Wireless Status Indicates whether the wireless network is up or
down.
Broadcast SSID? Indicates whether or not the SSID is being
broadcast.
Encryption Mode Displays the encryption method currently in use.
Distance Indicates the distance setting, as configured on the
Configuration > Wireless > Advanced Settings
page.
Wireless Bridge Mode Indicates whether this is a Root or Non-Root Bridge.
Aiming Action The Start Aiming link initiates the aiming process.
This is the same as pressing the blue button on the
outside of the bridge.
Channel Optimizer The Start Channel Optimizer Process link initiates
a progressive channel scan to determine the optimal
channel for the wireless link. This process is
disruptive to your wireless link, and may take several
minutes to complete, depending on the number of
channels available in your country or region.
Site Survey Click the ReScan button to immediately scan the
nearby area for interference from other 802.11
devices. Click Last Survey to view the results of the
last scan.
Link Status Indicates whether the link between Root and Non-
Root bridges is up or down.
Connected Devices Provides information on the peer device(s)
connected to this device. If the bridge link is down,
“No Association” will be displayed.
Table 7. The Status > Wireless page
