Figure 1: ZF7055 front view
Table 2: ZF7055 front view features
DescriptionNameNumber
Pass through port.Pass Through port1
Optional 48V DC power
input.
Power Input2
Three 10/100 RJ-45
Ethernet Ports.
LAN1-LAN33
One 10/100 RJ-45 LAN port
with PoE out. Supports
802.3af PSE Class 0/2
(depending on power input).
LAN44
Refer to “Reset Buttons”
below for details.
Reset buttons5
Rear Panel Features
The following figure shows the rear panel of the 7055. For a description of each rear
panel element, refer to the table below.
10
ZoneFlex Indoor Access Point Release 104.0 User Guide
Introduction
Getting to Know the AP Features
