Figure 2: ZF 7055 rear panel
Table 3: ZF 7055 rear panel features
DescriptionNameNumber
Uplink LAN port that
supports 802.3af and
802.3at Power over
Ethernet (PoE) input.
PoE In LAN/Uplink1
110 punchdown block.Punch down Block2
RJ-45 pass through port for
the pass through
connection.
Pass Through Port3
See LEDs table for LED
descriptions and behaviors.
LEDs4
ZoneFlex Indoor Access Point Release 104.0 User Guide
11
Introduction
Getting to Know the AP Features
