LEDs
Refer to the table below for descriptions of LEDs and their behaviors. The LEDs are not
visible once the AP is installed.
Table 4: ZF 7055 LEDs
DefinitionLED
• Off: Off
• Red: Bootup in process
• Flashing Green: No routable IP address
• Green: On
PWR
• Green: Link up.
• Flashing green: Activity.
• Off: Link down.
WAN
• Off: The WLAN service is down.
• Amber: The WLAN is up, but no clients
are associated and no downlink MAPs
are connected.
• Green: The WLAN is up and at least
one client is associated. No downlink
MAPs are connected.
• Slow flashing green (one flash every two
seconds): The WLAN is up and at least
one downlink MAP is connected. No
clients are associated.
• Fast flashing green (two flashes every
second): The WLAN is up, at least one
downlink MAP is connected, and at
least one client is associated.
5G
• Off: The WLAN service is down.
• Amber: The WLAN is up, but no clients
are associated and no downlink MAPs
are connected.
• Green: The WLAN is up and at least
one client is associated. No downlink
MAPs are connected.
2.4G
12
ZoneFlex Indoor Access Point Release 104.0 User Guide
Introduction
Getting to Know the AP Features
