DefinitionLED
• Off: The AP is operating in standalone
mode or operating as a root AP (RAP)
or a non-mesh AP.
• Green: The AP is functioning as a Mesh
AP (MAP), and the wireless signal to its
uplink AP is good.
• Fast flashing green (two flashes every
second): The AP is functioning as a
Mesh AP (MAP), and the wireless signal
to its uplink AP is fair.
• Slow flashing green (one flash every two
seconds): Mesh networking is enabled,
but the AP is still searching for a mesh
uplink.
AIR
• Off: The AP is not being managed by a
Ruckus Wireless controller (standalone
mode).
• Green: The AP is being managed by a
Ruckus Wireless controller.
• Slow flashing green (one flash every two
seconds): The AP is being managed by
a controller, but is currently unable to
communicate with the controller.
• Fast flashing green (two flashes every
second): The AP is being managed by
a controller and is currently receiving
configuration settings (provisioning) or
an image update.
DIR
• Green: Link up.
• Flashing green: Activity.
• Off: Link down.
LAN1 - LAN4
Reset Buttons
Two reset buttons on the left side of the AP are used to reboot or factory reset the AP.
ZoneFlex Indoor Access Point Release 104.0 User Guide
13
Introduction
Getting to Know the AP Features
