English
8
41
OPTIO
N NO.
MENU ITEM
Description
BASIC
COFFEE
PARAMETERS
It is possible to set:
- The name of the ingredient
- The doses (water and powder)
- Dispense a test beverage
For appliances with a payment system, it is possible to set the change in the price of the selection.
BASIC
MILK
PARAMETERS
It is possible to set:
- The name of the ingredient
- The doses (milk)
- Dispense a test beverage
BASIC
HOT
WATER
PARAMETERS
It is possible to set:
- The name of the ingredient
- The doses (water)
- Dispense a test beverage
ADVANCED
COFFEE
PARAMETERS
MINIMUM QUANTITY OF BEVERAGE (in impulses)
OFFSET TEMPERATURE
This function makes it possible to regulate a possible increase/decrease of the coffee's temperature in the cup.
It allows to lower or increase the temperature of the product on a range between -5 and +5.
Double shot
If active, this function performs double brewing of coffee for single drink dispensing.
PRE-INFUSION TIME
Sets the pre-infusion time before the actual infusion occurs.
PRE-INFUSION DOSE
Sets the quantity of water (in impulses) to be used during pre-infusion.
ADVANCED
MILK
PARAMETERS
AIR PWM PERCENTAGE
Allows to regulate the quantity of cream in the cup (0% unfrothed milk, 100% completely frothed milk).
2.4.1Recipes in useMakes it possible to customise the recipes of the beverages displayed in the machine.
2.4.2Recipes availableMakes it possible to customise the recipes of the beverages available but not displayed in the machine.
2.4.3Recipes not availableMakes it possible to customise the recipes not available in the machine because of the configuration.
2.5ContainersAccording to the machine layout, how the product containers have been arranged can be shown.
Choose a container in order to:
- Assign a name to the container.
- Associate an ingredient to the container (Coffee beans, Coffee beans 2, fresh milk, …)
- Change the colour associated with the container.
3Machine settingsThis menu makes it possible to access the settings of the machine.
3.1Machine ConfigurationMakes it possible to access the configuration group database of the machine.
3.1.1Selection of the
configuration
Allows the appliance's group and individual configurations to be managed.
A group of configurations contains multiple individual configurations (layout).
Groups of configurations and individual configurations can be deleted and duplicated.
When using a new configuration, you can decide whether to reset the statistical data, calibrations, and maintenance counters or not.
Before uploading the configuration of another appliance (cloning), make sure that the two appliances' settings are compatible.
3.1.2Backup and RestoreBackup
Allows the machine settings to be saved as a backup file.
RESTORE
Allows the backed-up machine settings to be restored.
The appliance can be restored to its:
- Factory settings
- Previously-saved custom settings.
After having restored the settings from the configuration file, enable the configuration from the "Selection of the configuration" menu.
3.1.3Import from a USBAllows the new machine settings to be imported from a configuration file that has been saved onto a USB memory stick.
The import function can be used to clone the settings of another appliance; make sure that the two appliances' settings are compatible.
3.1.4Export via a USBAllows the machine settings to be exported into a configuration file on a USB memory stick.
The export function can be used to clone current settings onto another appliance; make sure that the two appliances' settings are compatible.
3.2Configuration of the
translation
3.2.1Edit TranslationsThe names of the beverages, recipes, containers and nutritional information, which are displayed on the screens, can be changed in the available
languages.
The programming menu strings cannot be changed.
3.3Display settings
3.3.1Customising the
interface graphics
Allows customisation of certain graphical elements of the user interface.
3.3.1.1EditAllows some user interface graphics to be set, such as backgrounds, text size, colours, etc.
3.3.1.2SelectAllows to choose the file with the custom graphics to apply to the user interface.
The files uploaded via the "import" function will be displayed.
3.3.1.3Import interface
graphics
Allows the custom graphics files on the USB memory stick to be browsed through and selected, in order to be imported onto the appliance.
3.3.1.4Export interface
graphics
customisation
Allows the custom graphics to be saved onto a USB memory stick.
