Register Communications Ports
Standard Ports
PORT CONNECTOR TYPE
ETHERNET Standard RJ45/8 wire
SERIAL #1 PC type DB9/male
SERIAL #2 Standard RJ45/8 wire
SERIAL #3 Standard RJ45/8 wire
DRAWER 2 Standard RJ45/6 wire
Optional Ports
PORT CONNECTOR TYPE
SERIAL #4 Standard RJ45/8 wire
Pin Descriptions
SIGNALS
PIN# Serial
Port 1
Serial
Port 2
Serial
Port 3
Serial
Port 4~7
IRC
Port
Drawer
Port 1
Drawer
Port 2
Drawer
Port 3
1
/DCD NC Vcc NC TPTx+ FGND FGND FGND
2
RxD RxD /DSR /DSR TPTx- Solenoid(-) Solenoid(-) Solenoid(-)
3
TxD TxD TxD TxD TPRx+ COMP1 COMP2 COMP3
4
/DTR /DTR RxD RxD NC 24V 24V 24V
5
GND GND NC NC NC Solenoid(-) Solenoid(-) Solenoid(-)
6
/DSR /DSR NC NC TPRx- GND GND GND
7
/RTS /RTS GND GND NC
RJ-11 (Modular 6Pin)
8
/CTS /CTS /DTR /DTR NC
9
Vcc Vcc
RJ-45 (Modular 8Pin)
CONN. D-SUB9(Male)
