Sam4s SER-7040 - IRC Test

SER-7000 Program Manual S-Mode Programming
x
27
IRC Test
IRC TEST
1. REGISTER # SETTING
2. INTERNAL LOOPBACK(CHIP)
3. INTERNAL LOOPBACK(DRIVER)
4. EXTERNAL LOOPBACK
5. IRC SYSTEM TEST
1. Select IRC from the
H/W TEST MENU to
display the IRC
TEST menu.
2. Select "1. Register
# Setting" to enter the
IRC register number
(1-32).
Select 2 - 5 for a
specific test. Refer
to the table below for
an explanation of
each test.
3. Press any key to end
the test and return to
the IRC TEST menu.
# TEST Notes
2 INTERNAL LOOPBACK
(CHIP)
Tests the internal IRC integrated circuit. Test
runs continuously counting success (S) and failure
(F).
3 INTERNAL LOOKBACK
(DRIVER)"
Tests the internal IRC driver. Test runs
continuously counting success (S) and failure (F).
4 EXTERNAL LOOPBACK
This test requires a loopback connector. Test
runs continuously counting success (S) and failure
(F).
5 IRC SYSTEM TEST
Test sends packet to each register in the range
input. Test runs continuously counting success
(S) and failure (F).
