S-Mode Programming SER-7000 Program Manual
Serial Port Device Selections
Use the Serial Port Device Selections program to define the type of device that is attached to
each serial port.
SERIAL PORT DEVICE SELECTIONS
PORT DEVICE
---- ------------
PORT#1 DISABLE
PORT#2 DISABLE
PORT#3 DISABLE
PORT#4 DISABLE
ESC ENTER PAGE UP/DN
np
SERIAL PORT DEVICE SELECTIONS
PORT DEVICE
---- ------------ --------
PORT#1 DISABLE
PORT#2 PRINTER
PORT#3 VIDEO
PORT#4 POLLING
ESC ENTER PAGE UP/DN
np
SERIAL PORT DEVICE SELECTIONS
PORT DEVICE
---- ------------ --------
PORT#1 SCALE
PORT#2 SCANNER
PORT#3 EFT TERM.
PORT#4 CHANGER
ESC ENTER PAGE UP/DN
np
SERIAL PORT DEVICE SELECTIONS
PORT DEVICE PRINTER TYPE
---- ---------- ------------
PORT#1 DISABLE SAM SRP100
PORT#2 PRINTER SAM SRP270
PORT#3 VIDEO SAM SRP350
PORT#4 POLLING CTZEN 3551
ESC ENTER PAGE UP/DN
np
1. Select SERIAL
PORT DEVICE
SELECTIONS from
the S-MODE
PROGRAMMING
MENU .
2. Press the
n
or
p
keys
to select the port you
wish to view or edit.
3. To change a port
selection, press
ENTER to move the
active cursor to the
device selection
column.
4. Press the
n
or
p
keys
to select a new
device, press
ENTER.
5. If there are multiples
of the selected device
(i.e. many types of
printers) the options
will display.
6. Press the
n
or
p
keys
to select a new type
and press ENTER to
accept the new
selection.
7. Press ESC to return
to the SERIAL PORT
DEVICE
SELECTIONS screen
with port selection
active.
8. Press ESC again to
return to the S-
MODE
PROGRAMMING
MENU.
