S-Mode Programming SER-7000 Program Manual
Keyboard Key Relocation
KEYBOARD KEY RELOCATION
1. PLU KEYS
2. WLU KEYS
3. FUNCTION KEYS
ESC ENTER PAGE UP/DN
np
KEYBOARD KEY RELOCATION
1. PLU KEYS 1. KBD LEVEL 1
2. WLU KEYS 2. KBD LEVEL 2
3. FUNCTION 3. KBD LEVEL 3
4. KBD LEVEL 4
5. KBD LEVEL 5
ESC
np
1. Select KEYBOARD
KEY RELOCATION
from the S-MODE
PROGRAMMING
MENU to display the
KEYBOARD KEY
RELOCATION
Screen.
2. Press a numeric digit
(1-3) or press the
n
or
p
keys to move the
cursor to your choice.
Then press ENTER
to indicate whether
you wish to program
a PLU, WLU or
FUNCTION key.
3. A pop up window
displays the keyboard
level selection.
Select the keyboard
level you wish to
program, press
ENTER.
