Function block parameters (CO4)
Limiting factor (F03 - 1) 0.1 to 10.0
Analysis to terminals 03/13 (F04 - 1) AnA, bin
Stop parallel operation in case of deviation (F06 - 1) 0 to 10 min
Flow limit temp. f. parallel pump operation (F06 - 1) 20 to 90 °C
Activate priority in case of deviation (F08 - 1) 2 to 10 min
Correction factor (F08 - 1) 0.1 to 10.0
Activate priority in case of deviation (F09 - 1) 2 to 10 min
Proportional gain K
P
(F12 - 1) 0.1 to 50
Reset time T
N
(F12 - 1) 1 to 999 s
Derivative-action time T
V
(F12 - 1) 0 s; Do not change!
Valve transit time T
Y
(F12 - 1) 5 to 240 s
Hysteresis (F12 - 0) 1 to 30 °C
Min. ON time (F12 - 0) 0 to 10 min
Min. OFF time (F12 - 0) 0 to 10 min
Max. system deviation (F13 - 1) 2 to 10 °C
Day of the week (F14 - 1) 1–7, 1 to 7
Start time (F14 - 1) 00:00 to 23:45 h
Stop time (F14 - 1) 00:00 to 23:45 h
Disinfection set point (F14 - 1) 60 to 90 °C
Set point boost (F14 - 1) 0 to 50 °C
EB 5575 EN 127
Appendix
