Samson TROVIS 5575 - Page 128

Parameters in level 5
Parameter (PA5) Level 5 Range of values
Vacation
01.01 to 31.12
Vacation period, Start
01.01 to 31.12
Vacation period, Stop
Assignment to control circuit Rk1, Rk2, Rk4
Vacation period, Start
01.01 to 31.12
Vacation period, Stop
Assignment to control circuit Rk1, Rk2, Rk4
Function block parameters (CO5)
Start summer mode (F04 - 1) 01.01 to 31.12
Number of days until activation (F04 - 1) 1 to 3
Stop summer mode (F04 - 1) 01.01 to 31.12
Number of days until deactivation (F04 - 1) 1 to 3
OT limit value (F04 - 1) 0 to 30 °C
Delay (F05/6 - 1) 1 to 6 °C/h
Frost protection limit (F09 - 0) –15 to 3 °C
Max. limit value (F10 - 1) 3 to 500
pulse
h
Max. limit value heating (F10 - 1) 3 to 500
pulse
h
Max. limit value DHW (F10 - 1) 3 to 500
pulse
h
Limiting factor (F10 - 1) 0.1 to 10.0
Lower measuring range value (F11 - 1) 0/4 mA
Upper measuring range value 20 mA (F11 - 1) 0.01 to 650
m
h
3
Max. limit value (F11 - 1) 0.01 to 650
m
h
3
Max. limit value heating (F11 - 1) 0.01 to 650
m
h
3
Max. limit value DHW (F11 - 1) 0.01 to 650
m
h
3
Limiting factor (F11 - 1) 0.1 to 10.0
Binary input bE (F12 - 1) 1, 0
128 EB 5575 EN
Appendix
