System Anl 1.6 (all versions of TROVIS 5575-00xx)
System Anl 1.6
With pre-control
Anl 1.6
Without pre-control
Integration of VF4, UP1 Possible Not possible
ZP integration with CO4 ->
F10 - 1 (broken line, see cover)
Possible Possible
Note
– VF1 takes the position of VF4;
RüF1 is to be installed in the heat
exchanger
Default setting
CO1 -> F03 - 1 (with RüF1)
CO4 -> F01 - 1 (with SF1)
CO4 -> F02 - 1 (with SF2)
CO4 -> F05 - 0 (without VF4)
34 EB 5575 EN
Systems
BE
BA
AE
RK
WW
KW
SF2
ZP SLP
UP1 VF1
VF4 SF1
RK1
RüF1
