Disassembly and Reassembly
Samsung Electronics 129
No. Work Procedure Remark
13 - Remove the power and control wires and connectors
from the Fan PBA.
- To replace with a module assembled with the case,
heat sink and PBA, unfasten the four screws on the case.
Fan PBA
3-2-14 Removal Instructions for the Fan PBA
3-2 Disassembly and Reassembly (cont.)
