Disassembly and Reassembly
Samsung Electronics 93
No. Work Procedure Remark
2 1) Removing the Panel Front-UPR, RH
- The Panel Front-UPR, RH is hung on the side frame,
using supportive tabs.
- Slightly lift and pull the panel towards you, and
then detach it downwards.
Supportive tabs
Supportive tabs
3-2 Disassembly and Reassembly (cont.)
3-2-2 Removal Instructions for Panel
