Product Specifications
Samsung Electronics 11
2-1-6 Structure of product (DVM S WATER)
Small size
CONTROL BOX
Liquid Pipe
High pressure Gas Pipe
Low pressure Gas Pipe
4 WAY V/V
Receiver
Plate Heat Exchanger
Accumulator
Sub Cooler
Compressor
Oil separator
Large size
Liquid Pipe
4 WAY V/V
Accumulator
CONTROL BOX
Oil separator
Compressor
High pressure Gas Pipe
Low pressure Gas Pipe
Sub Cooler
Plate Heat Exchanger
Receiver
2-1 Feature of Product (cont.)
