Product Specifications
Samsung Electronics 9
2-1 Feature of Product (cont.)
2-1-4 Structure of product (Heat Recovery: AMSSSSXVSSR Series )
Small size
Large size
Heat exchanger
CONTROL BOX
4-WAY V/V
Intercooler
Accumulator
Low Pressure
Gas Pipe
Oil separator
Compressor
High Pressure Gas Pipe
Liquid pipe
Heat exchanger
4-WAY V/V
Accumulator
Intercooler
Low Pressure
Gas Pipe
High Pressure Gas Pipe
Liquid pipe
Compressor
Oil separator
CONTROL BOX
