Samsung AM080FX A Series User Manual

PBA Diagram and Parts List
Samsung Electronics 260
①
WCOMP W
②
UCOMP U
③
VCOMP V
④
CN22DOWNLOAD
#1 : COMP W #1 : COMP U #1 : COMP V #1: RXDOWN
#2: TXDOWN
#3: BOOT
#4: TDO
#5: TCK
#6: TDI
#7: TMS
#9: GND
#10: VCC
⑤
CN32  MAIN COMM
⑥
CN702REACTOR1
⑦
CN701REACTOR2
⑧
CN91FAN DC
#1 : 12VMAIN
#2 : INSMPSRELAY
#3 : COMMIN
#4 : GNDMAIN
#1: REACTOR1 #1: REACTOR2 #1: 18V
#2: GND
#3: 5VFAN
#4: ADSELECT
⑨
CN15FAN DC LINK
⑩
CN13AC POWER
⑪
RINPUT R TOP
⑫
SINPUT S TOP
#1 : AC
#2 :
#3 : AC
#1: AC LIVE
#2: AC NEUTRAL
#3: AC NEUTRAL
#1: RIN #1: SIN
⑬
TINPUT T TOP
#1: TIN
5-3 ASSY PBA INVERTER
(cont.)
- Model : AM240/260HXVSSS, AM240/260JXVSSS, AM160/180/240/260/280/300KXVASS,
AM160/240/260/280KXVGSS, AM080KXVSSS
