Installer reference guide / Mono tank integrated type 128
Step 1 Step 2 Step 3 Description Default
Connection
Information
Number of Connection - 0 to 16 -
View Master Indoor Unit - Address -
Master Indoor Zone
Information
Serial No. - -
Indoor Unit Eva In Temp.
(Teva_in)
Temperature -
Indoor Unit Eva Out Temp.
(Teva_out)
Temperature -
Indoor Unit PHE IN(Tw1) Temperature -
Indoor Unit PHE OUT(Tw2) Temperature -
DHW Tank Temp.(Tt) Temperature -
DHW Mode
Economic/Standard/Power/
Forced
-
Device Information
Micom Code - Micom code -
Program Version - Modified date -
Touch Code - Touch IC code -
Program Version - Modified date -
Graphic Image - Graphic image code -
Program Version - Modified date -
Reset All Service
Modes
Erase All Service mode
data
- - -
Initialize a remote
controller
- - -
Power Master Reset
1)*
- - - -
ODU K3 Reset - - - -
Indoor Unit Option
Address
Main address 00 to 4F -
RMC address 00 to FE -
Product Option
2)*
-
Refer to the installation
manual of the connected
indoor unit.
-
Installation Option 1
2)*
- - -
Installation Option 2
2)*
- - -
MCU Port
MCU address 00 to 15 -
MCU Port A to F -
1)* Power Master Reset is a setting needed to supply optimized power to wired remote controller when multiple indoor units are connected to wired
remote controller in a group.
2)* The total option codes are 24 digits. You can set six digits at a time and it is distinguished by page number. Press the button to move to the next page.
To Next Page
