Installer reference guide / Mono tank integrated type 45
Open
1 Remove the 4 screws of the side panel.
2 To remove the front panel, slide it up and pull it out.
3 Remove the panel. Remove the drain hole if necessary.
11
12
13
5.2 Indoor unit installation
Preparing the installation location of the indoor unit
• The indoor unit is designed for indoor installation only and for the following room temperatures:
– 5~35°C (heating)
– 5~40°C (cooling)
Avoid installing against outer walls with a risk of freezing.
WARNING
• To handle, purge, and dispose the refrigerant, or opening the refrigerant circuit, the worker should have a
certificate from an industry-accredited authority.
Choosing the installation site
The indoor unit should be installed indoors and meet the following conditions.
• In area with suitable space for servicing.
• A place with adequate ventilation.
• The construction for installation is a flat, capable of supporting the operational weight of the unit.
