7. Electrical installation
Installer reference guide / Mono tank integrated type 94
To connect the wired remote controller
Dimension
120
120
19
(Unit : mm)
Wired remote controller installation
1 Insert the flat-head screwdriver into two square grooves at the bottom of the wired remote controller and rotate it to
lift the front cover for removal from the rear cover.
To Next Page
