7. Electrical installation
Installer reference guide / Mono tank integrated type 81
Specification of power cable
• 1 Phase
– The power cables are not supplied with the air to water heat pump.
– Power supply cords of parts of appliances for outdoor use shall not be thinner than polychloroprene sheathed
flexible cord (Code designation IEC:60245 IEC 57 / CENELEC:H05RN-F)
– This equipment complies with IEC 61000-3-12.
Outdoor
unit
Model
Rated Voltage Range MCA MFA
Hz Volts Min Max
Min. Circuit
Amps.
Max. Fuse
Amps.
Mono HT
Quiet
AE080BXYDEG
50 220-240 198 264 26 A 28.6 A
AE120BXYDEG 50 220-240 198 264 32 A 35.2 A
AE140BXYDEG 50 220-240 198 264 32 A 35.2 A
Mono
AE050RXYDEG
50 220-240 198 264 16 A 20.0 A
AE080RXYDEG
50 220-240 198 264 22 A 27.5 A
AE120RXYDEG
50 220-240 198 264 28 A 35.0 A
AE160RXYDEG
50 220-240 198 264 32 A 40.0 A
• 3 Phase
– The power cables are not supplied with the air to water heat pump.
– Power supply cords of parts of appliances for outdoor use shall not be lighter than polychloroprene sheathed
flexible cord (Code designation IEC:60245 IEC 66 / CENELEC:H07RN-F)
– This equipment complies with IEC 61000-3-12 provided that the short-circuit power (SSC) is greater than or equal
to 3.3[MVA] at the interface point between the user's supply and the public system. It is the responsibility of the
installer to ensure, by consultation with the energy company if necessary, that the equipment is connected only to a
supply with a short-circuit power (SSC) greater than or equal to 3.3[MVA].
Outdoor
unit
Model
Rated Voltage Range MCA MFA
Hz Volts Min Max
Min. Circuit
Amps.
Max. Fuse
Amps.
Mono HT
Quiet
AE080BXYDGG
50 380-415 342 457 16.1 A 17.7 A
AE120BXYDGG 50 380-415 342 457 16.1 A 17.7 A
AE140BXYDGG 50 380-415 342 457 16.1 A 17.7 A
Mono
AE080RXYDGG
50 380-415 342 457 10 A 16.1 A
AE120RXYDGG
50 380-415 342 457 10 A 16.1 A
AE160RXYDGG
50 380-415 342 457 12 A 16.1 A
