Installing and Replacing a Local Antenna
The 403- to 470-MHz, 2-dBi antenna includes an omnidirectional antenna with an N-male
connector.
STEP 1. Remove the protection cap attached to the antenna connector terminal at the
bottom of the communications gateway box.
STEP 2. Screw in the antenna to the N-type female connector.
STEP 3. Waterproof the connector to industry standards.
Installing Local
Antenna
904-002450-02
STEP 1. Visually inspect the antenna for damage (bent, not vertical)
STEP 2. If it needs to be replaced, remove any waterproong material around the
connector.
STEP 3. Unscrew the antenna.
STEP 4. Check to ensure the connector channel is clear.
STEP 5. Follow the procedure outlined in the previous section: “Installing Local
Antenna.”
Replacing a Local
Antenna
