8 S&C Instruction Sheet 461-509
Mounting, Powering, and Securing the Communications Gateway
Figure 1. The TripSaverII Communications Gateway.
Gateway
Controller
Module
Battery
Module
PS/Battery Board
Antenna
Radio
Ground wire
Ac line fuse
