Sartorius Picus 2 User Manual

Picus
®
2 Operating Instructions 15
Operating Design
4.2.1 Displays in Menus
2
1
3
4
5
Fig. 6: Displays in menus (example)
Pos. Name Description
1 Menu entry Yellow background: Currently selected.
2 Main menu Contains available operating modes and settings menu.
3 Advanced functions Number and type of advanced functions. The number varies according to the
activated operating mode.
4 On | Off bar — If the dark bar is on the right: the function is activated.
— If the dark bar is on the left: the function is deactivated.
5 Selection parameters Are Predefined abd selectable with the scrollwheel.
