2 Operating Instructions 17
Operating Design
Symbol Designation Description
NO
[NO] softkey — Does not apply the changes.
— Does not execute the action.
YES
[YES] softkey — Applies the changes.
— Does execute the action.
PREV
[PREV] softkey With activated protocol: returns to the previous protocol step.
NEXT
[NEXT] softkey With activated protocol: skips to the next protocol step.
ABC
[ABC] softkey — Indicates that upper case is activated.
— With softkey pressed: switches to [abc] function.
abc
[abc] softkey — Indicates that lower case is activated.
— With softkey pressed: switches to [123] function.
123
[123] softkey — Indicates that numbers are activated.
— With softkey pressed: switches to [#@!] function.
#@!
[#@!] softkey — Indicates that special characters are activated.
— With softkey pressed: switches to [CLEAR] function.
CLEAR
[CLEAR] softkey — Deletes the text.
— With softkey pressed: switches to [ABC] function
4.4 Indicators in the Display
Symbol Designation Description
Indicator [Charge status] — Shows the current charge status of the device.
— If the battery level is low: the indicator flashes.
Indicator [Indicator arrow] Indicates which pipetting process is selected: aspirate or dispense.
Indicator [Dispensing
speed]
Shows the dispensing speed.
Indicator [Aspiration speed] Shows the aspiration speed.
Indicator [Blowout] Shows that the additional function [Blowout] is activated.
Indicator [Bluetooth] Shows that Bluetooth is activated.
Indicator [Counter] Shows that the additional function [Counter] is activated.
Indicator [Plate Tracker] Shows that the additional function [Plate Tracker] is activated.
Mix
Indicator [Mix] Shows that the additional function [Mix. pre. asp.] and/or [Mix. post disp]
is activated.
Delay
Indicator [Delay] Shows that the additional function [Auto] is activated.
