Satec PM172EH series Reference Guide

22
Table 4-44 Write Request
Message type (ASCII)
‘l’
Message body (hexadecimal)
Request
Field Offset Length Parameter Range
1 0 2 Data log number 0-7 = log #1-#8
2 2 2 The number of parameters in the record 1-16
3 4 4 Log parameter #1 ID see Table 5-7
4 8 4 Log parameter #2 ID see Table 5-7
5 12 4 Log parameter #3 ID see Table 5-7
6 16 4 Log parameter #4 ID see Table 5-7
7 20 4 Log parameter #5 ID see Table 5-7
8 24 4 Log parameter #6 ID see Table 5-7
9 28 4 Log parameter #7 ID see Table 5-7
10 32 4 Log parameter #8 ID see Table 5-7
11 36 4 Log parameter #9 ID see Table 5-7
12 40 4 Log parameter #10 ID see Table 5-7
13 44 4 Log parameter #11 ID see Table 5-7
14 48 4 Log parameter #12 ID see Table 5-7
15 52 4 Log parameter #13 ID see Table 5-7
16 56 4 Log parameter #14 ID see Table 5-7
17 60 4 Log parameter #15 ID see Table 5-7
18 64 4 Log parameter #16 ID see Table 5-7
Response
Field Offset Length Parameter Range
1 0 2 Data log number 0-7 = log #1-#8
1. The memory partition must be allocated for the log before setting up its parameters.
2. If a partition has been allocated as a TOU profile log partition, the data log setup for the partition cannot be written. Write
requests will be ignored. A read request will return identifiers of the TOU season tariff energy registers 0x7000 to 0x700F.

Satec PM172EH series Specifications

General

Brand	Satec
Model	PM172EH series
Category	Measuring Instruments
Language	English
