Description
BASO-2 - 02.02 - V07 Page 2-5
2.2. Operating data of the coffee machine
2.2.1. Characteristics of the coffee machine
The coffee machine is capable of supplying 100-120 cups of coffee or tea
per hour.
2.2.2. Dimensions of the coffee machine
Width 420 mm
Height 755 mm
Depth 510 mm
Outlet height 80-180 mm
Net weight 45 kg (15 SO-2)
Subject to modification!
2.2.3. Power supply
Model Connected load
1 SO-2 steam 6.2 kW / 16 A 400 V AC (3 PNE) 50/60 Hz
1 SO-2 tea 6.2 kW / 16 A 400 V AC (3 PNE) 50/60 Hz
15 SO-2 9.2 kW / 16 A 400 V AC (3 PNE) 50/60 Hz
For special voltages ask the manufacturer or one of your authorized after
sales service people.
Danger!
• An authorized specialist must install or inspect the installation!
• The phase must be fuse-protected with 16A.
• Never use a machine with a defect mains cable. Let an authorized spe-
cialist replace a defect mains cable or plug immediately.
• Use only an extension cord when you are sure that it is in perfect condi-
tion. The extension cord must have a minimum cross section of 1.5 mm²
for each core and a permitted 5 pole plug (PNE) for 16 A.
• Mains cable and/or extension cords must be placed so that no one can
fall over them. Don’t crush or pull the cords around corners and sharp
edges and don’t let them hang exposed in the room. Don’t place the
cords on warm surfaces and protect them from oil and harsh cleaning
agents.
• Never lift or pull the machine by the mains cable. Never pull the plug by
the mains cable or extension cord out of the socket. Never touch cord
and plug with wet hands. Never insert a wet plug in the socket.
Attention!
Mains connection according to local regulations. The voltage on the rating
plate must correspond to the local mains voltage.
