Schaerer Ambiente 2 User Manual

Cleaning
Weekly cleaning coffee machine with fridge
Page 5-22 BASO-2 - 01.05 - V07
20.1 Connect the short
white tube (a) with the
tube nipple to the milk baffle (b) of the T-
piece (c) (connection to the fridge).
20.2 Connect the long
white tube (d) with the
tube adapter to the tube nipple of the T-
piece (c) (connection to the coffee machine).
21.1 Place the blue tube (f) in the retainer (d).
21.2 Place the white tube (e) with the T-piece (c)
in the retainer (d).
21.3 Pull the tubes with the tube adapter to the
foamer head in the coffee machine.
21.4 Connect the expander (a) and the baffle (b)
with the T-piece (c).
22.1 Connect the white tube (a) to the rear nipple
of the foamer head (c).
22.2 Connect the white tube (a) to the rear nipple
of the foamer head (c).
Attention!
Make sure that the tubes (a and b) and the
tube adapter are connected according to
color as shown in the picture.
23. Put the tube adapter (c) back into the foamer
head (d).
23
b (white) a (blue)
weiss
schwarz
c
d
20
Coffee machine
Fridge
Milk
a b c d
21
c
a
b
f
e
d
22
a
b
c
ª
