3 Initial Preparation
3.2 Connection to a Host System
Page 24
BP-200 plus
Art. no.: 2.510701 rev.: c
3.2 Connection to a Host System
The following SCHILLER units can be used as the host system:
CS-200
AT-10 plus
AT-104 (without QRS trigger)
•AT-110
•AT-10
•AT-60
CS-100
3.2.1 Interconnections and Settings
When connecting to a host system the following connections must be made:
RS-232 cable assembly - for data transfer and BP-200 plus control.
Trigger cable - for QRS trigger point detection
The specific unit connectors and settings, exercise protocols and measurement
intervals are detailed in the relevant user guide for the host system. The cable
assemblies required for the host systems are detailed in the accessories section (see
page 56).
Following are two typical examples of the connections and settings required to
connect and setup the BP-200 plus for host system operation. The two examples are
for the CS-200 and for the AT-10 plus. Other host systems will be similar - please
consult the relevant user guide.
