Page 33
Art. no.: 2.510701 rev.: c
Blood Pressure Measurement 4
User Guide Using the BP-200 plus in Standalone Mode 4.2
BP-200 plus
4.2.4 Taking Measurements at predefined intervals
1. Position cuff on the patient (see page 27).
2. If carrying out a stress test position the ECG electrodes (with ECG / SpO2 version
only).
3. Define the Measurement Interval (see Setup above) between 2 and 20 minutes
and press the Measurement key to start a measurement program at the set
interval defined.
The defined measurement interval is shown on the top left information line, and a
count-down timer displays the time until the next measurement will be initiated.
