Schiller BP-200 plus - Spo2 Module and ECG Amplifier Option; Spo 2 - Pulsoximetry; ECG Amplifier

Page 55
Art. no.: 2.510701 rev.: c
Technical Data 8
User Guide SpO2 Module and ECG Amplifier Option 8.2
BP-200 plus
8.2 SpO2 Module and ECG Amplifier Option
8.2.1 SpO
2
- Pulsoximetry
8.2.2 ECG Amplifier
Module
Masimo™
Amplifier
Fully isolated, defibrillation protected >5kV
Sampling Frequency
62.5 Hz
Operation
Normal and high
Accuracy
SpO
2
PP
• Adults 70 to 100% ± 2 digits
• 30 ... 199/min ± 4 digits
Calibration range
70 ... 100% (calibration is fixed, no calibration required)
Measurement range
SpO
2
PP
• 1 ... 100%
• 25 ... 240/min
Sensor Temperature
The maximum temperature generated by the sensor at the sensor - tissue interface
is < 41
o
PP Calculation
Averaged over 8 beats
Standard
ISO 9919:2005 Medical electrical equipment - Particular requirements for the basic
safety and essential performance of pulse oximeter equipment for medical use
ECG amplifier
Sampling frequency
Digital Resolution
Protection
Dynamic range
Max. electrode potential
Frequency response
Input impedance
Common mode rejection
• 500 Hz
• 2.5 µV 12 bit
• Fully isolated, defibrillation protected >5kV
• ±5.12 mV AC
• ±300 mV DC
• 0.05 to 150 Hz (-3 dB)
• >10 MOhms
• >80 dB
Safety standard IEC/EN 60601-1, CF classified (with internal power supply) IEC/EN 60601-2-25
EMC IEC/EN 60601-1-2
Conformity CE according the directive 93/42/EEC, class IIa
