6 Maintenance
6.6 Cleaning
Page 46
BP-200 plus
Art. no.: 2.510701 rev.: c
6.6.4 Removing the Microphone and Inflation Bladder
• Slide your hand into the cuff and pull out the inflation bladder.
• Gently remove the microphone by pushing out from the microphone pouch.
• Disconnect the pressure hose from inflation bladder if required by gently pulling the
hose away for the inflation bladder connector (1).
V Do not pull on the microphone lead or hose as this can cause damage to the
connections.
