Page 47
Art. no.: 2.510701 rev.: c
Maintenance 6
User Guide Cleaning 6.6
BP-200 plus
6.6.5 Re-inserting the Microphone and Inflation Bladder
Re-insert the microphone and inflation bladder in the reverse order as described
previously.
Please note the following:
• The metallic side of the microphone must be facing upwards when inserting in the
cuff (the metallic side faces the patient).
• Ensure that the microphone is correctly inserted in the cuff. It must fully reach the
bottom of the pouch.
The hose/microphone assembly between the cuff and the unit can be positioned so
that it exits from the top or the bottom of the cuff according to user preference.
When re-inserting the microphone, make sure that the microphone cable goes over
the inflation bladder.
