Page 41
Art. no.: 2.510701 rev.: c
SpO2 and Peripheral Pulse 5
User Guide Placing the Sensor 5.2
BP-200 plus
5.2 Placing the Sensor
The Pulse Oximetry uses an ear clip reusable sensor that is placed on the patient‘s
ear lobe.
When using for stress testing form a stress loop in the cable and secure the cable to
the patients clothing with the crocodile clip on the cable to provide strain relief.
Alarms
V No Spo2 alarms will be displayed if communication fails between Sensor and
Massimo Sp02 module or a general module failure. The values for PP and Spo2
shows in this case two dashes.
V No alarm settings are provided for SpO2
