4.2.6 SWS 020 / 021 / 041 / 060
NOTE
The rubber bushings are located at the SWS020 in SWA and not,
as shown here, in SWK.
SWK
Exemplary design shown on SWK021
1 Alignment pin
2 Locking mechanism
3 Locking ball
4 Pneumatic feed-through with rubber bushing
5 Air supply lock and unlock
SWA
Exemplary design shown on SWA021
1 Bearing race with recesses for locking balls
2 Alignment pin bushing
3 Pneumatic feed-through
4 Port for pneumatic feed-through
