SCHUNK SWS 001 - Sws 046

Assembly
68
12.00 | SWS | Assembly and Operating Manual | en | 389456
5.3.10 SWS 046
Dimensions of the compressed air connections
SWS Pneumatic feed-throughs Air supply lock and unlock
046 -* G1/8"
* Pneumatic feed-through possible with optional modules
Pneumatic connection SWK046
1 Air supply unlock
2 Air supply lock
