Assembly
70
12.00 | SWS | Assembly and Operating Manual | en | 389456
5.4 Mounting the sensor
The product is equipped for the use of sensors.
• For the exact type designations of suitable sensors, please see
catalog datasheet and Overview of sensors [
}
70].
• For technical data for the suitable sensors, see Assembly and
Operating Manual and catalog datasheet–which can be found
at schunk.com.
• Information on handling sensors is available at schunk.com or
from SCHUNK contact persons.
5.4.1 Overview of sensors
The piston stroke control checks whether the locking mechanism is
locked or unlocked. Depending on the size, the piston stroke
control is integrated or can be mounted externally.
The presence monitoring of the SWA checks whether SWK and
SWA are coupled or not. A sensor is attached to the SWK for this
purpose. A presence signal is transmitted on contact with the
sensor target integrated in the SWA.
SWS Piston stroke control
Presence
monitoring of the
SWA
integrated external
001 -
005 -
007 X
011 X
011HM X
020 X
020HM X
021 X
021HM X
040Q X
041 X
046 X
060 X
071 X
076 X X
110 X X
160 X X
The catalog data sheet contains more information.
