Technical data
26
04.00 | WSG 50 | Assembly and operating manual | en | 389474
Requirement for the power supply
• Voltage supply: 24 V DC ±10%
• Ripple <150 mV
SS
• Available output current: at least 3 A
The following cables from SCHUNK are suitable for connecting the
voltage supply:
• Type: KA GLN0806-LK-00500-A power cable 5 m,
4 pole. M8 connector straight on RJ-45, ID. no. 0307787
• Type: KA WLN0806-LK-00500-A power cable 5 m,
4 pole. M8 connector at an angle on RJ-45, ID. no. 0307785
NOTICE
Please note that the maximum cable length of 15 m for
communication via RS232 must not be exceeded. In an
environment with severe electromagnetic disturbances, e.g.areas
near large electric drives, this length mustbe further reduced in
some circumstances. If in doubt, perform some tests.
Interface specification RS232:
Parameter Unit Min. Type Max. Remark
Output level (TxD) V ±5.0 ±5.7 Load resistance = 3 kΩ
Input voltage range (RxD) V -30 30 relative to GND
High input level V -30 1.3 relative to GND
Low input level V 2.4 30 relative to GND
Supported bit rates kBit/s 1.2; 2.4; 4.8; 9.6; 19.2;
38.4; 57.6; 115.2; 230.4;
460.8
Data format 8 data bits, no parity,
1 stop bit (8n1)
Flow control none
