Operation
04.00 | WSG 50 | Assembly and operating manual | en | 389474
45
7 Operation
A high performance gripper control unit is integrated into the
product. Access to the gripper control unit is possible be removing
the cover with the SCHUNK logo.
Opening to access the gripper control unit
1 Micro SD memory card 3 Test interface
(For use only by
Manufacturer)
2 Communication LEDs
Via this opening you can see some other indicator LEDs as well as
the control unit's memory card. The test interface is only used by
the manufacturer for programming and test purposes and is not
needed during the unit's production process.
7.1 Operating software
The software needed to operate the product is already installed in
the unit.
NOTE
• To guarantee proper operation, the latest version of firmware
should always be installed in the product.
ð The latest firmware can be obtained from the SCHUNK.
