Assembly
04.00 | WSG 50 | Assembly and operating manual | en | 389474
37
NOTICE
Material damage due to incorrect tightening torques!
Observe the maximum tightening torque:
– Screw M3: 1.0 Nm
– Screw M6: 3.0 Nm
