Operation
48
04.00 | WSG 50 | Assembly and operating manual | en | 389474
The following operating states are indicated:
State Display
Loading the operating software
The product loads the firmware and gets ready to start.
Blue, constantly on
There was an error loading the operating software
The boot process will automatically be restarted
Red for about 5 seconds,
then blue again
The boot process for the operating software
The operating software will be started and the control
system will be configured.
Blue, flashing
Wait state
The product is ready for operation and is waiting for a
command.
White, slowly pulsating
Busy
The product is in the initialization phase or is currently
executing a command.
White, quickly pulsating
Executing a script
A script is being executed by the control system.
Green, quickly pulsating
Warning
One or more parameters have reached warning limits.
Please check the system’s status via its web interface.
Yellow, quickly pulsating
Command received with no errors
The product has received an error-free command.
Green, pulses once
Error carrying out a command
An error has occurred while receiving or executing a
command.
Red, pulses once
Critical fault
An error has occurred (e.g. excess temperature, loss of
communications, etc.). This error must be acknowledged
before the product can process new commands to move.
Red, pulses quickly
Critical fault
A serious error has occurred and the execution of the
software in the unit has been stopped. The product will
restart after a short time.
Red, flash code 2x short,
long pause
More LEDs indicating SD card and communication activity can be
found next to the SD card slot under the cover plate with the
SCHUNK logo.
