3-42 Communications Date Code 20011026
SEL-321/321-1 Instruction Manual
Table 3.19: Set G Command Description
Button
Pushed Results Displayed Comment
SET
SET GROUP
SELECT ↑ ↓ ← →
Pressing SET causes the display to come up in
SET GROUP. Press (←) to get to SET G.
←
SET G
SELECT ↑ ↓ ← →
Press SELECT to enter the editing mode for SET
G settings.
SELECT
SET G
IN1 = 52A1
Shows present setting for first setting category:
IN1. Press (↓ or →) to move to next category.
↓
SET G
IN2 = PT
Next setting category is displayed. Press (↓ or ←)
to return to previous category.
↑
SET G
IN1 = 52A1
Returns to previous category. Press SELECT to
display possible selections for this category.
SELECT
SET G
IN1 = 52A1 *
(*) at end of line shows you are in list function.
Press (← or →) to move through list of entries.
→
SET G
IN1 = 52A2 *
New entry is shown for IN1. While in list
function, press (↑ or ↓) to insert or remove NOT
(!) function in front of entry.
SELECT
SET G
IN2 = PT
List function is exited, new setting for IN1 was
saved, and next category (IN2) is displayed.
Table 3.20: Set P Command Description
Button
Pushed Results Displayed Comment
SET
SET GROUP
SELECT ↑ ↓ ← →
Pressing SET causes the display to come up in
SET GROUP.
→
SET P
SELECT ↑ ↓ ← →
Press (→) to step through setting choices.
SELECT
SET P 1
SELECT ↑ ↓ ← →
Press (→) to select the port desired. Shows Port 1
selected. Press SELECT to enter edit mode.
SELECT
SET P 1
PROTOCOL = SEL
Shows present protocol setting for this port. Press
(↓) to move to next setting category for Port 1.
