Table 3-19: Mode Run Menu Parameters
OPTION DESCRIPTION
Audio3 Output Volume
Audio3 Volume Control
(Available ONLY for the IRD-2800).
Selects the volume level (gain/attenuation) for Audio3 Output analog
and digital signals.
Available options:
from –58 dB (min) to +06 db (max) in 2 dB steps – analog values.
Digital values are shifted down by –06 dB (i.e., from –64 dB to 00 dB).
Audio1 (DAC) Output Type
Audio1 DACOutput Type
Selects the modulation type for the Audio 1 Digital to Analog Converter
(DAC).
Options available:
MONO MIXING:
Mixes left and right stereo channels signals for mono output on both
LEFT and RIGHT connectors.
STEREO (LEFT & RIGHT):
Standard stereo output on the respective LEFT&RIGHT connectors.
BOTH RIGHT:
Outputs right channels on both LEFT and RIGHT connectors.
BOUT LEFT:
Outputs left channels on both LEFT and RIGHT connectors.
SWAP (LÆ
ÆÆ
Æ, RÆ
ÆÆ
ÆL):
Swaps outputs;
-Left channels on RIGHT connectors.
-Right channels on LEFT connectors.
Audio2 (DAC) Output Type
Audio2 DAC Output Type
(Available ONLY for the IRD-2800).
Selects the modulation type for the Audio 2 Digital to Analog Converter
(DAC).
Options available:
MONO MIXING:
Mixes left and right stereo channels signals for mono output on both
LEFT and RIGHT Audio connectors.
STEREO (LEFT & RIGHT):
Standard stereo output on the respective LEFT&RIGHT connectors.
BOTH RIGHT:
Outputs right stereo on both LEFT and RIGHT connectors.
BOUT LEFT:
Outputs left stereo on both LEFT and RIGHT connectors.
SWAP (LÆ
ÆÆ
Æ, RÆ
ÆÆ
ÆL):
Swaps outputs;
-Left channels on RIGHT connectors.
-Right channels on LEFT connectors.
